    ISO|SK| BT|HSK Tool Holders Machine Tool Shanks Tapers Toolholders Dimensions


    ISO|SK| BT|HSK Tool Holders Machine Tool Shanks Tapers Toolholders Dimensions

    Different country’s standards occurs different tool holders. There are mainly two parts, one is 7:24 universal tapers, like ISO, BT, CAT, SK Series, another is 1:10 HSK hollow shank taper.
    Different machine use different shank tooling system.


    As 7:24 universal tapers have many standards, they looks alike, but some demensions still different.
    MAS BT shank is Japanese standard, BT Tool Holders have BT30, BT40, BT50, with keyway and non-keyway
    DIN 69871 shank also called SK shank, JT shank, DIN, DAT, DV Shank, there are SK30, SK40, SHK50 shanks
    ISO 7388/1 shank, also called IV or IT shank.
    ANSI B5.50, famous as CAT shank, there are CAT40, CAT50, CAT60
    HSK series have 6 sizes, HSK-A, HSK-B, HSK-C, HSK-D, HSK-E, HSK-F.

    Machine Tool Shanks Tapers Dimensions:
    BT shanks tapers dimensions
    SK DIN ISO shanks tapers dimensions
    cat shanks tapers dimensions

    hsk shanks tapers dimensions

    Rico CNC supplies a range of toolholder fork fingers for tool magazines, such as ISO10, ISO15, ISO20, ISO25, ISO30, SK40, JT40, JT50, BT30, BT40, BT50, HSK25E, HSK32E, HSK40E, HSK50E, HSK63A|E|F, etc, you can check in our cnc spare parts.

    Welcome your inquiry.
