2-250-19-4040 70x18x25mm Pressure Roller Wheels with Countersink for Brandt Edgebanders

2-250-19-4040 70x18x25mm Pressure Roller Wheels with Countersink for Brandt Edgebanders

• 2-250-19-4040 upper pressure roller
• Pressure wheels 70*18*25 for Brandt
• Upper pressure roller 70x18x25 with countersink
• Brandt pressure roller with counter sunk
• Upper pressure wheel 18/29x25x70mm counter sunk
• Spare parts for BRANDT edgebander
• Brandt edgebanding machine pressing wheel
• Top pressure roll for Brandt
INQUIRY

2-250-19-4040 70x18x25mm Pressure Roller Wheels with Countersink for Brandt Edgebanders

This 2-250-19-4040 is the upper rubber pressure roller for Homag BRANDT edgebander. Inner diameter for axle is 18 mm, with a recess for a 5 mm axle-bolt head. It is the 70x18x25mm gear pressure wheel with 30mm diameter countersink.
70x18x25mm roller.jpg

70*18*25mm Brandt pressure roller parameters:
Straight gear pressure roller without bearing
Outer diameter = 70 mm
Inner diameter = 18 mm
Height/Width = 25 mm
Countersink type, countersink diameter 30mm, depth 5.4mm
rubber pressure roller for brandt.jpg
