Acrylic plexiglass Cutting Single Flute CNC Router Bits
Product Name:
Acrylic plexiglass Cutting Single Flute CNC Router Bits
Number :
Specialized acrylic cutting router bits
:
:

Product Description:

acrylic plexiglass cutting single flute cnc router bits

Acrylic plexiglass Cutting Single Flute CNC Router Bits

These solid carbide single flute spiral router bits are made especially for acrylic cutting.
Acrylic sheet is widely known as Plexiglas or Plexiglass, cutting acrylic on a cnc wood router is very popular in advertising signs making industry. But to route a clear edge on acrylic is not easy if you choose a normal wood cutting bits, as cutting and chip removal are much more important.
Standard wood or metal router bits won’t do the best result with chip removal and can cause a rougher cutting edge.

Be sure to use a specialized router bit, specifically designed for cutting acrylic, single flute, spiral up cutter, made from high quality solid carbide. Single flute cutters throw out the plastic chips nicely and there seems to be no or little heating, so no melting or sticking. And specialty design makes extra relief behind the cutting edge to prevent heat build up.

Specialty Single Flute Acrylic Bits Sizes:

Item No

CED

CEL

SHK

OVL

Y1LX3.06

3.175

6

3.175

40

Y1LX3.08

3.175

8

3.175

40

Y1LX3.10

3.175

10

3.175

40

Y1LX3.12

3.175

12

3.175

40

Y1LX3.15

3.175

15

3.175

40

Y1LX3.17

3.175

17

3.175

40

Y1LX3.20

3.175

20

3.175

45

Y1LX3.22

3.175

22

3.175

50

Y1LX3.25

3.175

25

3.175

50

Y1LX3.28

3.175

28

3.175

55

Y1LX3.32

3.175

32

3.175

60

Y1LX412

4

12

4

40

Y1LX415

4

15

4

40

Y1LX417

4

17

4

45

Y1LX422

4

22

4

50

Y1LX425

4

25

4

50

Y1LX428

4

28

4

55

Y1LX432

4

32

4

60

Y1LX442

4

42

4

70

Y1LX512

5

12

5

46

Y1LX517

5

17

5

50

Y1LX522

5

22

5

50

Y1LX525

5

25

5

55

Y1LX617

6

17

6

50

Y1LX622

6

22

6

50

Y1LX625

6

25

6

50

Y1LX628

6

28

6

55

Y1LX632

6

32

6

60

Y1LX642

6

42

6

80

Y1LX652

6

52

6

90

Y1LX6.17

6.35

17

6.35

50

Y1LX6.22

6.35

22

6.35

50

Y1LX6.25

6.35

25

6.35

55

Y1LX825

8

25

8

60

Y1LX835

8

35

8

80

Y1LX845

8

45

8

90

Y1LX855

8

55

8

100

Y1LX1025

10

25

10

60

Y1LX1035

10

35

10

80

Y1LX1045

10

45

10

90

Y1LX1055

10

55

10

100

Y1LX1235

12

35

12

80

Y1LX1245

12

45

12

90

Y1LX1255

12

55

12

100



RicoCNC also supplies standard single flute upcut spiral bits, single spiral router bits especially for Aluminum, also single flute compression spiral bits, and other cnc cutter bits and spare parts.

Payment could be made by Paypal, Western Union, MoneyGram, T/T bank transfer, etc.

Welcome your inquiry.
