SHARP TFT-LCD Display Module LQ10D368

• LQ10D368
• TFT-LCD Module
• SHARP LCD Module LQ10D368
• color active matrix LCD module
• LCD display LQ10D368
• Sharp Microelectronics
• 246.5(W)x179.4(H)x11.0max(D)
• SHARP LCD display screen
INQUIRY

SHARP TFT-LCD Display Module LQ10D368

This module is a color active matrix LCD module incorporating amorphous silicon TFT(Thin Film Transistor). It is composed of a color TFT-LCD panel, driver ICs, the model number is LQ10D368, control circuit and power supply circuit and a backlight unit. Graphics and texts can be displayed on a 640x3x480 dots panel with 262,144 colors by supplying 18 bit data signal(6bit/color), four timing signals,+3.3V/ +5V DC supply voltage for TFT-LCD panel driving and supply voltage for backlight.

color active matrix LCD module.jpg

Specifications of LQ10D368:

Parameter	Specifications	Unit
Display size	26 (10.4")Diagonal	cm
Active area	211.2(H)x158.4(V)	mmm
Pixel format	640(x480(V) (1 pixel=R+G+B dots)	pixel
Pixel format	640(x480(V) (1 pixel=R+G+B dots)
Pixel pitch	0.330(H)x0.330(V)	mm
Pixel configuration	R,G,B vertical stripe
Display mode	Normally white
Unit outline dimensions *1	246.5(W)x179.4(H)x11.0max(D)	mm
Mass	520(max)	g
Surface treatment	Anti-glare and hard-coating 3H

LCD display LQ10D368.jpg

The TFT-LCD panel used for this module is a low-reflection and higher-color-saturation type. Therefore, this module is also suitable for the multimedia use.
