This is HIWIN linear block HGH30CA is a HG series, square type, model size: 30, heavy duty. It is used for Homag, and Part number is 3-807-06-5940 or 3807065940

HIWIN Guide Carriage HGH30CA.jpg

HIWIN Guide Carriage HGH30CA specification:

Size: 30 mm

Block Type: Square

Load Type: Heavy Load

Block Mounting Type: from Top

Preload Code: ZA

Block Height: 45 mm

Block Width: 60 mm

Block Length: 97.4 mm

Thread Size: M8 x25

Basic dynamic load rating: 48.5 kN

Basic static load rating: 71.87 kN

Block Weight: 0.88 kg

Rail Width: 28 mm

Rail Height: 26 mm

3807065940 Guide Carriage .jpg

3-807-06-5940 3807065940 HIWIN Guide Carriage HGH30CA-Z0-H-SW Feature:

• By design, the circular-arc groove has contact points at 45 degrees. HG series can absorb most installation errors due to surface irregularities and provide smooth linear motion through the elastic deformation of rolling elements and the shift of contact points. Self-aligning capability, high accuracy and smooth operation can be obtained with an easy installation.

• Because of precision dimensional control, the dimensional tolerance of HG series can be kept in a reasonable range, which means that any blocks and any rails in a specific series can be used together while maintaining dimensional tolerance. And a retainer is added to prevent the balls from falling out when the blocks are removed from the rail.

• Because of the four-row design, the HG series linear guideway has equal load ratings in the radial, reverse radial and lateral directions. Furthermore, the circular-arc groove provides a wide-contact width between the balls and the groove raceway allowing large permissible loads and high rigidity.

 Guide Carriage HGH3 0 CA-Z0-H-SW.jpg

RicoCNC supply various of parts and tools for Homag, Biesse, SCM.

Please check our website, if you can not find, please contact us for more information!
