Products > Homag Spare parts

4011040944 Check Valve AVENTICS Pilot-operated Non-Return Valve for HOMAG

• 4011040944 check valve
• 4-011-04-0944 valve
• AVENTICS 0821003050
• HOMAG check valve
• AVENTICS check valve
• Pneumatic Valves Systems
• Pilot-operated non-return valve
• Series NR02
INQUIRY

4011040944 Check Valve AVENTICS Pilot-operated Non-Return Valve for HOMAG

This is a Pilot-operated non-return valve from AVENTICS, the model number is 0821003050, it is used for HOMAG machine, the HOMAG part number is 4011040944 or 4-01-104-0944.

4011040944 Check Valve specifications:

Compressed air connection 1	G 1/8
Compressed air connection type 1	Internal thread
Mounting	thread-in
Compressed air connection type 2	External thread
Type	Poppet valve
Compressed air connection 2	G 1/8
Compressed air connection 12	G 1/8
Nominal flow Qn 1 to 2	300 l/min
Working pressure min.	0.5 bar
Working pressure max	10 bar
Min. ambient temperature	-20 °C
Max. ambient temperature	80 °C
Min. medium temperature	-20 °C
Max. medium temperature	80 °C
Medium	Compressed air
Housing material	Brass
Seal material	Acrylonitrile butadiene rubber
