4011041592 4-011-04-1592 Solenoid Valve 0820061011 for HOMAG
This is a directional valve for HOMAG machine, the HOMAG part number is 4011041592 4-011-04-1592. It is AVENTICS ELECTRIC VALVE, SINGLE 5/3 G1/8 TC08.
4011041592 Solenoid Valve 0820061011 specifications:
| Activation | Electrically |
| Switching principle | 5/3, exhausted center |
| Actuating control | Double Solenoid |
| Manual override | with detent |
| Nominal flow Qn | 700 l/min |
| Compressed air connection output | G 1/8 |
| Min. working pressure | 3 bar |
| Max. working pressure | 10 bar |
| Operational↩voltage | 24 V DC |
| Voltage tolerance DC | -1 |
| Electrical connection type | Plug |
| Pilot valve width | 15 mm, Soft seal |
| Power consumption DC | 2 W |
| Duty cycle | 100% |
| Min. ambient temperature | -10 °C |
| Max. ambient temperature | 50 °C |
| Housing material | Polyamide fiber-glass reinforced |
