4086050682 Beckhoff EK1100 EtherCAT Coupler Interface Modules for Homag Machine

This module is Beckhoff EK1100 EtherCAT Coupler. It can be used on Homag woodworking machine and the part number is Homag 4086050682 / 4-086-05-0682.
HOMAG 4-086-05-0682 BECKHOFF EK1100 modules.jpg

The EK1100 coupler connects EtherCAT with the EtherCAT Terminals (ELxxxx). One station consists of an EK1100 coupler, any number of EtherCAT Terminals, and a bus end terminal. The coupler converts the passing telegrams from Ethernet 100BASE-TX to E-bus signal representation.
Homag 4086050682 modules.jpg

The coupler is connected to the network via the upper Ethernet interface. The lower RJ45 socket may be used to connect further EtherCAT devices in the same strand. In the EtherCAT network, the EK1100 coupler can be installed anywhere in the Ethernet signal transfer section (100BASE-TX) – except directly at the switch. The couplers EK9000 and EK1000 are suitable for installation at the switch.

Technical data of EK1100:

Task within EtherCAT system

coupling of EtherCAT Terminals (ELxxxx)   to 100BASE-TX EtherCAT networks

Data transfer medium

Ethernet/EtherCAT cable (min. Cat.5),   shielded

Distance between stations

max. 100 m (100BASE-TX)

Number of EtherCAT Terminals

up to 65,534

Protocol

EtherCAT

Delay

approx. 1 µs

Data transfer rates

100 Mbit/s

Bus interface

2 x RJ45

Power supply

24 V DC (-15 %/+20 %)

Current consumption from US

70 mA + (∑ E-bus current/4)

Current consumption from UP

load

Current supply E-bus

2000 mA

Power contacts

max. 24 V DC/max. 10 A

Electrical isolation

500 V (power contact/supply   voltage/Ethernet)

Operating/storage temperature

-25…+60 °C/-40…+85 °C

EMC immunity/emission

conforms to EN 61000-6-2/EN 61000-6-4

Relative humidity

95 %, no condensation

Vibration/shock resistance

conforms to EN 60068-2-6/EN 60068-2-27

Protect. rating/installation pos.

IP20/variable

Approvals/markings

CE, UL, ATEX, DNV GL, IECEx, cFMus

Beckhoff EtherCat Coppler EK1100.jpg

EL1809, EL2809, EL1008, EL2008, EK1100, KL2541, BK1120, EL1889, EL2889, EL5101, EL4001, EL6731, BK1250, EL3314, EL6751, EL9410, EL7041, KL1859, EK1122, EL1088, EL5151, EL5001, EK1828, EK1818 also are available here.
Beckhoff modules.jpg

RicoCNC can offer a range of Homag machine spare parts and industrial automation parts and components to all over the world.
