BOSCH AVENTICS 0820055052 Rexroth 0-820-055-052 Pneumatic Directional Control Valve HF03 - 5/2SR - 024DC

This pneumatic valve is 0-820-055-052 AVENTICS pneumatic directional valve. It is widely used in Homag machines.
AVENTICS Formerly BOSCH REXROTH Pneumatic.
0820055052 Aventics Pneumatic Directional Valve.jpg

0820055052 Pneumatic valve specification:

Activation

Electrically

Nominal flow Qn

850 l/min

Switching principle

5/2

Working pressure min.

-0.9 bar

Working pressure max

10 bar

DC operating voltage

24 V

Voltage tolerance DC

-15% / +20%

Manual override

without detent  0820055051 with detent

Actuating control

Single Solenoid

Sealing principle

Soft Seal

Pilot

External

Certificates

UR (Underwriters Laboratories)

Pilot valve width

16 mm

Valve type

Spool valve, positive overlapping

Connection type

Plate connection

Return

With spring return

Blocking principle

Single base plate principle

Control pressure min.

2.5 bar

Control pressure max.

10 bar

Min. ambient temperature

0 °C

Max. ambient temperature

50 °C

Min. medium temperature

0 °C

Max. medium temperature

50 °C

Medium

Compressed air

Max. particle size

5 µm

Single Solenoid Valve 0820055052.jpg
Rexroth 0-820-055-052 Pneumatic Directional Control Valve Features
• Modular design with up to 32 valves and 32 coils
• High flow rate with up to 850 l/min
• Pilot valve with 0.35 W per coil
• Optimized weight due to plastic base and end plates
• Direct mounting on assembly system profiles
• High connectivity through Multipol or Fieldbus connection
• Integrated fittings and all connections pointed in one direction
Valves and valve systems series HF03-LG.jpg

0820055052/0820055051/0820055102/0820055601/0820055501/0820055101 AVENTICS BOSCH REXROTH solenoid valves are also available.
0820055052 Ventil Pneumatic Directional Valve.jpg

If you can not find the models here, please send your details to us, we can help you find what you want!

Please contact us for Homag machine parts and industrial automation parts!
