4-008-61-0609 Sensor inductive.jpg

4-008-61-0609 4008610609 Inductive Switch M8X1 L=38 62 SN=4 NO IFM IE5288 Proximity Sensor



This is the replacement for Homag Sensor inductive, it is 4 mm Range, M8 Non-Flush, PNP-NO, 10-36 VDC, IE Series, IFM IE5288. Homag part number is 4-008-61-0609 or 4008610609.

4008610609 Inductive Switch.jpg

Inductive sensor IE5288 IEK3004-BPKG/US-104 features:

For use where space is restricted

Long sensing range for high uptime

Robust metal housing for use in harsh industrial environments

Very high switching frequency

Clearly visible indication of the switching status

 IFM IE5288.jpg

4-008-61-0609 Inductive Sensor IFM IE5288 proximity switch specification:

Dimensions

Proximity Sensor Diameter

8.0 mm

Length

62 mm

Length (Straight Wireway)

62 mm

Details

Proximity Sensor Style

Cylindrical Proximity Sensor

Item

Cylindrical Proximity Sensor

Proximity Sensing Method

Inductive

Proximity Sensor Power Requirement

10 to 36V DC

Proximity Sensor Output Circuit Type

3 Wire PNP

Output Mode

NO

Max. Detecting Distance

4.0 mm

Proximity Sensor Electrical Connection

4 Pin M12 Connector

Shielded / Unshielded

Unshielded

Basic Proximity Sensor Case Material

Metal

Proximity Sensor Operating Frequency

300 Hz

Case Material

Brass White Bronze Coated

Description/Special Features

Overload And Short-Circuit Protection, Yellow LED Output Indication

IP Rating

67

Max. Current Load

200mA

Standards

CE Compliance

Includes

(2) Lock Nuts

Operating Temp. Range

-13 Degrees to 158 Degrees F

 ifm electronic IE5288.jpg

IFM proximity switch .jpg



There also other inductive sensors for Homag, such as:

4008611272 4-008-61-1272 Inductive Sensor IE5349

4008610712 4-008-61-0712 Inductive Sensor IE5338

4-008-61-0111 4008610111 Sensor inductive Holzma M12X1 L 44/56 SN 4 NO

4-008-61-0158 4008610158 Sensor inductive HOLZMA M12X1 L 44/56 SN 4 NC

4-008-61-0309 4008610309 sensor Proximity  PNP M18X1 L=48/59 SN=12 NO

4-008-61-0609 4008610609 Inductive Switch IFM IE5288

 M8X1 L=38:62 SN=4 NO.jpg

Sensor inductive for HOMAG WEEKE.jpg

RicoCNC can supply various of Homag/Brandt spare parts, please check our website, if you can not find, please contact us for more information!
