4008320849 Bernstein I88-UV1Z AH 618.6335.628 Medium Duty Limit Switches

4008320849 4-008-32-0849 Bernstein I88-UV1Z AH 618.6335.628 Medium Duty Limit Switches

This is a plastic body limit switch made by BERNSTEIN, the model number is I88-UV1Z AH, 618.6335.628. It is a with 1 NC and 1 NO contacts overlapping, slow made and break changeover. Normally used in Homag CNC woodworking machine, Homag part number is 4008320849 or 4-008-32-0849.

4008320849 I88-UV1Z AH limit switch specifciations:

Series I88 4-008-32-0849 618.6335.628 6186335781 features:

• Standard actuators to DIN EN 50047 type A

• Large range of actuators

• Snap action or slow make & break contacts

• Galvanically separated contacts

• Forced disconnection of NC contacts

• Protection class IP 65

• Body and lid PA 6 which is self extinguishing

• 4 x 90° actuator positions

• Cable entry M 20 x 1.5

• Terminals numbered in accordance with DIN EN 50013

• International approvals

Series I88 Benefits

• Hinged snap lid for quick and easy access (screwdriver release)

• Lid hinges open to 135° (can also be easily detached)

• Internal cover protects the contacts during mounting

• Screw terminals with self-lifting clamps for easy wiring

• Transparent cover for easy adjustment and inspection

Special features/variants (on request):

Available with black enclosure

Available with different actuating directions

With steel or different diameter roller

Bent or straight lever in different lengths
