4006103506 4-006-10-3506 HOMAG Bearing 6204-2RSLTN9

4006103506 4-006-10-3506 HOMAG Bearing 6204-2RSLTN9

• 4006103506 bearing
• DEEP GROOVE BALL BEARING DIN 625 6203-2RZ TN9 C3
• BALL BEARING 6204-2RS-Z-TN9-SKF
• BEARING 4-006-10-3506 HOMAG
• 6204-2RSLTN9/C3
• SKF Deep Groove Radial Ball Bearings 20x47x14mm
• Single row ball bearing
• Homag bearing
INQUIRY

4006103506 4-006-10-3506 HOMAG Bearing 6204-2RSLTN9

This is a deep groove radial ball bearing manufactured by SKF. Homag part number is 4006103506 or 4-006-10-3506. It is a Single Row Deep Groove Ball Bearing, Straight Bore, 20 mm ID, 47 mm OD, 14 mm Width, Double Sealed, Without Snap Ring, C3 Internal Clearance.

BEARING 4-006-10-3506 HOMAG.jpg

4006103506 ball bearing 6204-2RS-Z-TN9-SKF specification:

Indise Diameter (MM):	20MM
Ooutside Diameter (MM):	47MM
Width (MM):	14MM
Cage Type:	Plastic
Seals of Shields:	Two rubber seals
Clearance:	C3
Dynamic Load Rating (KN):	13.5
Static Load Rating (KN):	6.55
Fatigue Load Rating (KN):	0.28
Reference Speed Rating (R/MIN):	17000
Limiting Speed Rating (R/MIN):	32000
Bore Type	Straight
Closure Type	Double Sealed
