JS-36SG Precision Automatic Zero Tool setter for Engraving Machine

This is a Z-Axis Zero tool setter for engraving and milling machine, the model number is JS-36S(G) or JS-36SG. It is used for Jade machine, denture machine, high-gloss machine, glass machine, small engraving and milling machine.

Specification of JS-36SG tool setter:

External size(mm) 36*20*36(L×W×H)

Counter-face size(mm) φ10

Counter-face material Super hard alloy

Cable φ4*1m oil-resistant.2 cores

Tensile strength 20N Small bending radius R7

Protection tube 304 stainless steel hose 1m Small bending radius R7

Blowing device Option for combination type

Protection class IEC IP67

Tool setting signal mode NC (normally closed)

Input rating AC.DC5V-24V 20mA(*value 10mA) Resistive load

Operating life 3 million cycles

Pre-travel Almost zero

Total travel (mm) 4

Tool setting contact force 1.0N (mounting status: vertical or 90° side)

Repeatable tool setting accuracy 2μm (Operating speed: 50-200mm/min)

Over-travel protection None

LED light None

RicoCNC supplies a range of CNC spare parts and tools. JS-36S, JS-36S(G), JS-38S, JS-38S(G), JS-50R2P, JS-58RG2P, JS-45SR, JS-55RY, JS-66R, JS-66RM, JS-65RG, JS-65S, JS-65S(G), JS-68RG1F/JS-68RG2F, JD-8820, JS-100RG, JS-25R, JS-65R also have for supply, welcome your inquiry.
