JS-38SG High Precision Tool Setter for Milling Machine

JS-38SG High Precision Tool Setter for Milling Machine

This is a Z-Axis Zero tool setter for engraving and milling machine, the model number is JS-38S(G) or JS-38SG. This tool setter is suitable for Model Jade machine, Denture machine, Highlighting machine, Glass machine, Small engraving and milling machine.

It is one-piece contact head effectively prevents cutting powder and cutting oil from spilling into the internal part of the tool setter, ensuring high accuracy in harsh environments.

JS-38S(G) specification:

External size(mm): 45*25*38(L×W×H)

Counter-face size(mm): φ10

Counter-face material: Super hard alloy

Cable φ4*1m oil-resistant.4 cores

Tensile strength: 20N  Small bending radius: R7

Protection tube 304 stainless steel hose 1m Small bending radius R7

Tool setting signal mode: NC (normally closed)

Input rating: AC.DC5V-24V 20mA(*value 10mA) Resistive load

Operating life: 3 million cycles

Pre-travel: Almost zero

Tool setting contact force: 1.0N (mounting status: vertical)

Repeatable tool setting accuracy: 2μm (operating speed: 50-200mm/min)

Over-travel protection: NC (normally closed)

Special Notes

• the diameter of the tool should be controlled below 10mm in diameter.

• tool setting speed should be controlled below 50-200mm/min.

• the center of the tool should fall in the center of the tool setting surface.

• Do not rotate the head of the tool setting instrument by force.

• Ensure the levelness of the tool setting surface after installation.

• Please use the blowing device normally

• Use the ambient temperature range -25℃-70℃.

• the voltage should be controlled at 0-24V, the current is below 20mA, the recommended value is 10mA.

RicoCNC supplies a range of CNC spare parts and tools. JS-36S, JS-36S(G), JS-38S, JS-38S(G), JS-50R2P, JS-58RG2P, JS-45SR, JS-55RY, JS-66R, JS-66RM, JS-65RG, JS-65S, JS-65S(G), JS-68RG1F/JS-68RG2F, JD-8820, JS-100RG, JS-25R, JS-65R also have for supply, welcome your inquiry.
