T011 Double Flutes Melamine Chipboard CNC Wood Cutting Bits

T011 Double Flutes Melamine Chipboard CNC Wood Cutting Bits

• Tiger T011 CNC cutting bits
• 2 flutes compression TCT router bits
• Laminated chipboards cutting bits
• Double face laminated chipboards cutting bits
• Melamine board cutting bits
• Plywood CNC router bits
• CNC nesting wood bits
• Compression TCT router bits
INQUIRY

T011 Double Flutes Melamine Chipboard CNC Wood Cutting Bits

This is 2 flutes CNC cutting bits with 1/2‘’ inch shank diameter. These Tiger T011 series CNC wood router bits are 2 flutes compression TCT router bits. It is a chip-breaker design, especially suitable for double face laminated chipboards cutting. It has a better cutting edge of the top and bottom melamine veneer.
Tiger T011 CNC cutting bits.jpg

We recommend feed rate 10-15 meters/min, spindle speed 18000-24000rpm. And please be sure to use high-precision collets! Otherwise, it is easy to break!
Laminated chipboard cutting bits.jpg

T011 Tiger CNC nest cutting router bits features:
Material: KCR05 TCT carbide from Luxembourg
Fast feeding speed: 10-15m/min
Spindle speed: 18000-24000rpm
Nearly hundreds of sheets can be nest cut
Suitable for drilling, cutting, slotting, grooving, nesting, trimming, etc.
Double face laminated chipboards cutting bits.jpg

Below is the video about T011 wood cutting bits, welcome to check.
Working video: https://youtu.be/H-uyUHRLdjg

Compression TCT router bits.jpg

Here are the models of T011 bits can be chosen.

Part No.	Size	SHK	CED(mm)	CEL(mm)
T011-06-20	1/2620mm	1/2” (12.7mm)	6	20
T011-06-22	1/2622mm	1/2” (12.7mm)	6	22
T011-08-20	1/2820mm	1/2” (12.7mm)	8	20
T011-08-22	1/2822mm	1/2” (12.7mm)	8	22
T011-08-24	1/2824mm	1/2” (12.7mm)	8	24
T011-08-27	1/2827mm	1/2” (12.7mm)	8	27

Melamine board cutting bits.jpg

RicoCNC has a wide range of CNC cutting bits available, including up cut and down cut compression spirals, chip-breaker CNC bits. Whatever you’re cutting, from wood and plastics to foam, we have a tool for your application.
CNC nesting wood bits.jpg
