BOSCH AVENTICS 0821002003 Pneumatic Quick Exhaust Valve For Homag

BOSCH AVENTICS 0821002003 Pneumatic Quick Exhaust Valve For Homag

• Aventics quick exhaust valve 0821002003
• BOSCH 0 821 000 003 shuttle valve
• Bosch pneumatic valve 0821002003, G1/4
• Aventics Rexroth 0821002003
• BOSCH 0 821 002 003 quick exhaust valve
• Bosch 0821002003 quick-release valve
• Quick exhaust valve Bosch 0821002003
• 0821002003 Aventics pneumatic quick exhaust valve
INQUIRY

BOSCH AVENTICS 0821002003 Pneumatic Quick Exhaust Valve For Homag

This part is BOSCH AVENTICS 0821002003 pneumatic quick exhaust valve. It can be used on Homag woodworking machines.
Aventics quick exhaust valve 0821002003.jpg

Aventics Rexroth 0821002003.jpg

Below is the specification of the quick exhaust valve Bosch 0821002003
Type: Poppet valve
Medium: Compressed air
Compressed air connection input: G 1/4
Compressed air connection type 1: Internal thread
Compressed air connection 2: G1/4
Compressed air connection type 2: Internal thread
Port 3 (Exhaust): G 3/8
Compressed air connection type 3: Internal thread
Nominal flow Qn 1 to 2: 1000 l/min
Nominal flow Qn 2 to 3: 2050 l/min
Working pressure min: 0.5 bar
Working pressure max: 10 bar
Min. ambient temperature: 0 °C
Max. ambient temperature: 80 °C
Housing material: Aluminum
Seal material: Acrylonitrile butadiene rubber
BOSCH 0 821 002 003 quick exhaust valve.jpg
