MAZAK Rotary Union LX86M-234-11841 RIX ROCKY Rotary Joint

This is a built-in bearing type rotary joint from RIX, it is ROCKY rotary joint, LX-86M series, LX86M-234 LX86M-234-11841 for MAZAK machine.

LX86M-234 rotary union features:

• High-Pressure

• High-Speed

• Double drain structure (vertical mounting)

Fluid	Coolant	Oil Mist	Dry Air
Pressure (MPa)	0.5~7	0.2~1	N/A
Pressure (psi)	72.5~1,015	29~145	N/A
Pressure (bar)	5~70	2~10	N/A

Operating Specifications

Specification	Flow Rate (Coolant)	Max. Speed	Max. Temperature
Number	Below 20 L/min	Max. 15,000 min-1	Max. 60 ℃
Number	Below 5.28 gal/min	Max. 15,000 rpm	Max. 140 °F

RIX rotary union LX86M-234.jpg

There are also other RIX rotary joint here:

RIX L84J-244, ESX20M-7566YSUS, ESX20M-7566 , ESX20J-NO12, L84J,LA95, LA96, LX84M-234, LX84V-234, LX84V-244, LX84M-244, LX86M-23, LX86M-244, LX86V-244, L91M-234, L92M-234, L92M-244, L95M-234, L95M-224, L96M-234, L96M-244, EES-2P01, LA-1P01, LA-1P02, ES50-1600, ES50-2000, ESX20-NO12, ESX20-NO16, ESX20M-TO10, ES20M-TO10, EES-2P01, ESX20-8834, ESX10-8678, L60, LX88M-9801, ESX20M-TO10, ES20M-TO10, ESX20V-LO12, ESX20V-LO16, ESX20M-SO12, ESX20M-SO16, ESX20M-EO12, ESX20M-E016, ESX20M-LO16, ESX20M-NO16, ESX20M-NO12, ESX20M-7566YSUS, ESX20M-7566, etc.

MAZAK rotary union.jpg

Also other rotary joints:

G2008RUL0090 Coolant High Pressure Speed Rotary Joint

ACROW G200711M160180 Rotating Coolant Unions

RIX Rocky Rotary Joint For Machine Tool LX86V-244 LX86V-244C

ROTOFLUX High Speed Rotary Joint B08-1671-06E

Rotoflux Spindle Rotary Joints A10-1701-05L for High Speed Application and Dry Run

1101-235-238 Deublin Rotary Joint 3/8

A10-1371-05L A10-1301-05L ROTOFLUX Rotary Union High Speed Rotary Joint

Gu2000v High Speed Cooling Rotary Joint for CNC Machining Centers

LX84-7920 High Speed Rotary Joints RIX Rotary Union for Mazak Machine Tools

MAZAK Rotary Joint H50RK009190 ESX20M-7566SUS

MAZAK machine tool electric spindle RIX Rocky rotary joint H50RK008081 ESX20-6304

SM Rotation Unions GU2000V-S Special for Customer

C08-1351-01R ROTOFLUX for High Pressure and High Speed Applications

SMARTC Rotary Union EU2000 for CNC Machine Centers

etc.

There are also other top 4 brand rotary joints can be supplied here: DEUBLIN Rotary Joint, ROTOFLUX Rotary Joint, OTT-JAKOB Rotary Joint, SMARTC Rotary Joint.

Welcome to send inquiry to us!
